AD589LH データシート

Name: AD589LH
Brand: AD
SKU: 110014871-0000-0000-0000

AD589LH - AD の商品詳細ページです。

２営業日以内に回答いたします

AD589LH の詳細情報

型番	AD589LH
メーカー	AD
データシート
Analog IC - Other Type	TWO TERMINAL VOLTAGE REFERENCE
JESD-30 Code	O-MBCY-W2
JESD-609 Code	e0
Number of Functions	1
Number of Outputs	1
Number of Terminals	2
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Output Voltage-Max	1.25 V
Output Voltage-Min	1.2 V
Output Voltage-Nom	1.235 V
Package Body Material	METAL
Package Equivalence Code	SIP2,.1
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	240
Qualification Status	Not Qualified
Sub Category	Voltage References
Supply Current-Max (Isup)	5 mA
Surface Mount	NO
Technology	BIPOLAR
Temp Coef of Voltage-Max	25 ppm/Cel
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	WIRE
Terminal Pitch	2.54 mm
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	30
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	2.8 %

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
