AD584SH データシート

Name: AD584SH
Brand: AD
SKU: 110001988-0000-0000-0000

AD584SH - AD の商品詳細ページです。

２営業日以内に回答いたします

AD584SH の詳細情報

型番	AD584SH
メーカー	AD
データシート
Additional Feature	ADDITIONAL OUTPUT VOLTAGES OF 2.5V, 5V, 7.5V ALSO AVAILABLE
Analog IC - Other Type	THREE TERMINAL VOLTAGE REFERENCE
JESD-30 Code	O-MBCY-W8
JESD-609 Code	e0
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Output Voltage-Max	2.507 V
Output Voltage-Min	2.492 V
Output Voltage-Nom	2.5 V
Package Body Material	METAL
Package Equivalence Code	CAN8,.2
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	NOT APPLICABLE
Qualification Status	Not Qualified
Screening Level	38535Q/M;38534H;883B
Sub Category	Voltage References
Supply Current-Max (Isup)	1 mA
Supply Voltage-Max (Vsup)	30 V
Supply Voltage-Min (Vsup)	4.5 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	NO
Technology	BIPOLAR
Temp Coef of Voltage-Max	30 ppm/Cel
Temperature Grade	MILITARY
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	WIRE
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT APPLICABLE
Trim/Adjustable Output	NO V
Voltage Tolerance-Max	0.3 %

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
