AD5721RBCPZ-RL7 データシート

Name: AD5721RBCPZ-RL7
Brand: AD
SKU: 110258754-0000-0000-0000

AD5721RBCPZ-RL7 - AD の商品詳細ページです。

２営業日以内に回答いたします

AD5721RBCPZ-RL7 の詳細情報

型番	AD5721RBCPZ-RL7
メーカー	AD
データシート
Analog Output Voltage-Max	10.5 V
Analog Output Voltage-Min	-10.5 V
Converter Type	D/A CONVERTER
Input Bit Code	BINARY, 2'S COMPLEMENT BINARY
Input Format	SERIAL
JESD-30 Code	S-XQCC-N16
JESD-609 Code	e3
Length	3 mm
Linearity Error-Max (EL)	0.0122 %
Moisture Sensitivity Level	3
Negative Supply Voltage-Nom	-15 V
Number of Bits	12
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	UNSPECIFIED
Package Code	HVQCCN
Package Shape	SQUARE
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	0.8 mm
Settling Time-Nom (tstl)	9 us
Supply Voltage-Nom	15 V
Surface Mount	YES
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm

会社名称	アナログ・デバイセズ
設立	1965
所在地	One Technology Way P. O. Box 9106 Norwood, MA 02062-9106 United States
URL	http://www.analog.com/
