ASV-133.333MHZ-E-C-T データシート

Name: ASV-133.333MHZ-E-C-T
Brand: ABRACON
SKU: 110268672-0000-0000-0000

ASV-133.333MHZ-E-C-T - ABRACON の商品詳細ページです。

２営業日以内に回答いたします

ASV-133.333MHZ-E-C-T の詳細情報

型番	ASV-133.333MHZ-E-C-T
メーカー	ABRACON
データシート
Additional Feature	TRI-STATE; ENABLE/DISABLE FUNCTION; TR, 7 INCH
Fall Time-Max	4 ns
Frequency Adjustment-Mechanical	NO
Frequency Stability	50 %
Mounting Feature	SURFACE MOUNT
Number of Terminals	4
Operating Frequency-Max	200 MHz
Operating Frequency-Min	0.312 MHz
Operating Frequency-Nom	133.333 MHz
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
Oscillator Type	HCMOS
Output Load	15 pF
Package Body Material	PLASTIC/EPOXY
Package Equivalence Code	DILCC4,.2,200
Physical Dimension	7.0mm x 5.08mm x 1.8mm
Power Supplies	3.3 V
Qualification Status	Not Qualified
Rise Time-Max	4 ms
Sub Category	Other Oscillators
Supply Voltage-Max	3.63 V
Supply Voltage-Min	2.97 V
Supply Voltage-Nom	3.3 V
Symmetry-Max	40/60 %
