AB0815-T3 データシート

Name: AB0815-T3
Brand: ABRACON
SKU: 400059047-0000-0000-0000

AB0815-T3 - ABRACON の商品詳細ページです。

２営業日以内に回答いたします

AB0815-T3 の詳細情報

型番	AB0815-T3
メーカー	ABRACON
データシート
Clock Frequency-Max	0.032 MHz
Information Access Method	I2C; SERIAL, 4-WIRE/3-WIRE
JESD-30 Code	S-XQCC-N16
Length	3 mm
Moisture Sensitivity Level	1
Number of Terminals	16
Number of Timers	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	UNSPECIFIED
Package Code	HVQCCN
Package Shape	SQUARE
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	0.9 mm
Supply Voltage-Max	3.6 V
Supply Voltage-Min	1.5 V
Supply Voltage-Nom	1.8 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	30
Width	3 mm
uPs/uCs/Peripheral ICs Type	TIMER, REAL TIME CLOCK
