929870-01-05-RA データシート

Name: 929870-01-05-RA
Brand: 3M
SKU: 100109984-0000-0000-0000

929870-01-05-RA - 3M の商品詳細ページです。

２営業日以内に回答いたします

929870-01-05-RA の詳細情報

型番	929870-01-05-RA
メーカー	3M
データシート
Additional Feature	3M
Body Breadth	0.1 inch
Body Depth	0.15 inch
Body Length	0.5 inch
Body/Shell Style	SOCKET
Connector Type	BOARD CONNECTOR
Contact Finish - Mating	GOLD (10) OVER NICKEL (100)
Contact Finish - Termination	MATTE TIN OVER NICKEL
Contact Gender	FEMALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	1400VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
JESD-609 Code	e3
MIL Conformance	NO
Manufacturer Series	929
Mating Contact Pitch	0.1 inch
Mixed Contacts	NO
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of Connectors	ONE
Number Of PCB Rows	1
Number of Rows Loaded	1
Operating Temperature-Max	105 Cel
Operating Temperature-Min	-40 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	RECTANGULAR
Plating Thickness	10u inch
Rated Current (Signal)	1 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Terminal Length	0.125 inch
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	5
UL Flammability Code	94V-0
