37104-2165-000FL [ﾌﾞﾙｰ] データシート

Name: 37104-2165-000FL [ﾌﾞﾙｰ]
Brand: 3M
SKU: 40115878-0000-0000-0000

37104-2165-000FL [ﾌﾞﾙｰ] - 3M の商品詳細ページです。

２営業日以内に回答いたします

37104-2165-000FL [ﾌﾞﾙｰ] の詳細情報

型番	37104-2165-000FL [ﾌﾞﾙｰ]
メーカー	3M
データシート
Additional Feature	ROHS COMPLIANT
Body Breadth	0.23 inch
Body Depth	0.614 inch
Body Length	0.587 inch
Body/Shell Style	PLUG
Connector Type	BOARD CONNECTOR
Contact Design	PREASSEM CONN
Contact Finish - Mating	GOLD (8) OVER NICKEL (100)
Contact Gender	MALE
Contact Material	COPPER ALLOY
Contact Pattern	RECTANGULAR
Contact Style	SQ PIN-SKT
DIN Conformance	NO
Dielectric Withstanding Voltage	1400VAC V
Filter Feature	NO
IEC Conformance	NO
Insulation Diameter-Min	0.047 inch
Insulation Resistance	1000000000 ohm
Insulator Color	BLACK
Insulator Material	GLASS FILLED POLYETHYLENE
MIL Conformance	NO
Mating Contact Pitch	0.079 inch
Mixed Contacts	NO
Mounting Option 1	LOCKING
Mounting Type	CABLE
Number of Rows Loaded	1
Operating Temperature-Max	60 Cel
Operating Temperature-Min	-20 Cel
Option	GENERAL PURPOSE
Plating Thickness	8u inch
Polarization Key	POLARIZED HOUSING
Rated Current (Signal)	3 A
Reference Standard	UL
Reliability	COMMERCIAL
Sub Category	Headers and Edge Type Connectors
Termination Type	IDC
Total Number of Contacts	4
UL Flammability Code	94V-0
Wire Size-Max	20 AWG
Wire Size-Min	22 AWG
