10250-5202PL データシート

Name: 10250-5202PL
Brand: 3M
SKU: 20498757-0000-0000-0000

10250-5202PL - 3M の商品詳細ページです。

２営業日以内に回答いたします

10250-5202PL の詳細情報

型番	10250-5202PL
メーカー	3M
データシート
Board Mounting Option	HOLE .099-.111
Body/Shell Style	RECEPTACLE
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Gender	FEMALE
Contact Resistance	35 mohm
Dielectric Withstanding Voltage	707VAC V
Durability	300 Cycles
Empty Shell	NO
Filter Feature	NO
Insulation Resistance	500000000 ohm
Mating Contact Row Spacing	0.075 inch
Mating Information	MULTIPLE MATING PARTS AVAILABLE
Mixed Contacts	NO
Mounting Style	RIGHT ANGLE
Mounting Type	BOARD AND PANEL
Number of Ports	1
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	STAGGERED
Plating Thickness	8u inch
Rated Current (Signal)	0.5 A
Reference Standard	MIL
Terminal Length	0.154 inch
Termination Type	SOLDER
Total Number of Contacts	50
