10226-6202PL データシート

Name: 10226-6202PL
Brand: 3M
SKU: 20498749-0000-0000-0000

10226-6202PL - 3M の商品詳細ページです。

２営業日以内に回答いたします

10226-6202PL の詳細情報

型番	10226-6202PL
メーカー	3M
データシート
Board Mounting Option	HOLE .099-.111
Body Breadth	0.36 inch
Body Depth	0.23 inch
Body Length	1.46 inch
Body/Shell Style	RECEPTACLE
Connector Type	TELECOM AND DATACOM CONNECTOR
Contact Gender	FEMALE
Contact Pattern	RECTANGULAR
Contact Style	BELLOWED TYPE
Dielectric Withstanding Voltage	707VAC V
Empty Shell	NO
Filter Feature	NO
Insulation Resistance	500000000 ohm
Insulator Color	BLACK
Insulator Material	POLYBUTYLENE TEREPHTHALATE
Mixed Contacts	NO
Mounting Option 1	LATCH
Mounting Option 2	LOCKING
Mounting Style	STRAIGHT
Mounting Type	BOARD
Number Of PCB Rows	4
Number of Ports	1
Number of Rows Loaded	2
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-20 Cel
Option	GENERAL PURPOSE
PCB Contact Pattern	STAGGERED
PCB Contact Row Spacing	1.9 mm
Plating Thickness	30u inch
Rated Current (Signal)	1 A
Reference Standard	UL
Shell Finish	NICKEL
Shell Material	ZINC ALLOY
Terminal Length	0.134 inch
Terminal Pitch	2.54 mm
Termination Type	SOLDER
Total Number of Contacts	26
UL Flammability Code	94V-0
